Thermoplastic polyurethane with hardness 98 Shore A. A technical semi-flexible filament that offers great mechanical properties such as high tear and tensile strength.
It is characterized by highly reversible deformation, resistance to ozone, oils, greases, and aliphatic alcohols. Wear resistance guarantees the durability of 3D printed products. Great for the printing of continually sliding parts or sealings.
Features:
- Can be used for the final surface treatment
- Great interlayer adhesion ensuring tear strength in all the directions
- Excellent abrasion resistance
- High tensile strength
- Printing with 100% infill ensures tough object
- Improved UV stability
- Good rebound resilience
- High elasticity with highly reversible deformation
- Safe to use in electrical and electronic equipment
- Semi-flexible
- Low warping
- BPA-free and styrene-free
- Recyclable
BASIC PRINTERS SETUP
Printing Temperature: 220 – 240 °C
Bed Temperature: 50 – 60 °C
Printing Speed: 15 – 30 mm/s
Cooling Fan: 70- 100 %
Downloads:
Tech Specs: https://drive.google.com/file/d/16nWfofBg8NAJmiAH4TzWvvf4W56hqiRb/view?usp=drive_link
|
Flexfill TPU |
Flexfill TPE |
Flexfill PEBA |
Polymer base: |
Polyurethane + ester |
Polyolefin + SEBS |
Polyamide + ether |
Tensile strength: |
49 MPa |
5 MPa |
36 MPa |
Elongation at break: |
600 % |
250 % |
> 1000 % |
Density: |
1.20 g/cm³ |
1.15 g/cm³ |
1.00 g/cm³ |
Sensitivity to moisture: |
High |
Low |
High |
Chemical resistance: |
Oils, greases, ozone |
Water, acids, alcohols, alkalis |
Car fluids, toluene, acetone, ozone |
Food & skin contact: |
Not recommended |
Certificated |
Not certificated |
Gas permeability: |
High |
Low |
Medium |
Optical properties: |
Glossy, transparent |
Matte, non-translucent |
Glossy, very transparent |
For example, ideal for applications: |
Vibration: |
Anti-vibration, damping |
Anti-vibration, damping |
Vibration and energy transfer |
Skin contact: |
– |
Long-term touch of human skin (holding in hands) |
– |
Under temperature: |
+80–100 °C |
+80 °C |
-40 °C |
In contact with: |
oils |
water |
car fluids |
Abrasion: |
Sliding abrasion |
– |
Impingement abrasion |
Other: |
– |
Outdoor |
Low density |
Other: |
– |
– |
Rebounding |
